SONO MIX MINI LD- Moisture Sensors
SONO MIX MINI LD- Moisture Sensors
Features
Due to its small size, it is ideal for use in screws, with no or low electrical conductivity (0…2mS/cm) and bulk density (0.3…1.0kg/dm³)
| Temperature range | 0°C - +70°C |
| Power supply | +12V to +24V DC, approx. 3W |
| Special conditions | Measuring head can be temporarily loaded up to 150°C |
| Signal output | 2 x analog output 0(4)…20mA Output 1: Humidity in % Output 2: Temperature or optionally conductivity or standard deviation |
| Interfaces | RS485 or IMP bus |
| Sensor dimensions | Sensor Dimensions: 135 x 60 x 40 (Diameter x Length x Height) |
| Weight | 1.3 kg |
| IP protection class | IP67 |
